PCM2 D Colorimeter Intro

PCM2D-3-5-02

0.0001 - 5 000 cd/m²

Dual spot Colorimeter with 3 mm and 5 mm measurement spot

The PCM2D series features a cutting-edge optical engine for highest sensitivity with almost no light loss and enables simultaneous dual-spot color measurement. This patented technology ensures rapid, consistent performance, even at low luminance levels. The in-house designed and coated color filters are achieving best human visual perception using the CIE1931 standard, the system delivers outstanding color accuracy with every measurement.

  • Two measurement spots in one device, 3 mm and 5 mm
  • 10 mm pitch between both spots
  • Simultaneous measurement
  • Patented optical engine
  • Flicker luminance function: 3000 or 2000 samples/second

PCM2 D dual spot Colorimeter Highlights
Luminance range [cd/m²]
3 mm spot: 0.0003 - 15 000
5 mm spot: 0.0001 - 5 000
Chromaticity range [cd/m²]
3 mm spot: 0.003 - 15 000
5 mm spot: 0.001 - 5 000
Pitch between both spots 10 mm
Acceptance angle ± 10°
Working distance 5.67 mm

Overview of all Colorimeter Models
